| Classification: |
• |
6 Passengers |
• |
Berthing for 4 Passengers |
|
|
| Built: |
• |
1994 Winninghoff, Rowley, MA |
• |
Repower Date: 2008 |
• |
Aluminum Construction |
|
|
| Dimensions: |
• |
Overall Length 46’, Beam 15’, Draft 3’10” |
• |
Split Level Deck: |
| |
Upper Deck 9' x 14' |
| |
Lower Deck 11' x 13' |
|
|
| Mooring Systems: |
• |
Danforth Anchor |
• |
Anchor Windless |
|
|
Deck Winch: |
• |
Pulling Capacity: 2,200 lbs |
• |
Wire Capacity: 200 ft of 3/8" Wire |
|
|
Oceanographic Winch: |
• |
Manufacturer: InterOcean |
• |
Pulling Capacity: 1,000 lbs |
|
|
Horizontal Capstan: |
• |
Pulling Capacity: 5,000 lbs |
|
|
A-Frame: |
• |
Stationary |
• |
Max Safe Working Load: 1,000 lbs |
|
|
| Air Conditioning / Heating: |
• |
Number of units: 2 |
• |
Central AC |
|
|
| Machinery: |
• |
Main Engines: (2) John Deere 6081 375 Hp |
• |
Generators: (1) Northern Lights 8KW |
• |
Auxiliary Engine: Volvo 200 Hp Diesel |
• |
Hydraulic System: Dual control 100 GPM capability with deck mount quick disconnects |
• |
Auxiliary Engine Driven Fire Pump |
• |
Deck tie down points |
|
|
| Capacities: |
• |
Fuel Oil: 900 Gallons Total |
| |
Main Tanks: 400 Gallons |
| |
(2) Auxiliary Tanks: 250 Gallons each |
• |
Hydraulic Oil: 200 gallons |
• |
Potable Water: 40 Gallons |
• |
Cargo: 2 Long Tons |
| |
| Gally: |
• |
Microwave |
• |
Refrigerator |
• |
Coffee Maker |
• |
Seating for Four |
| |
| Electronics / Navigation: |
• |
VHF: (2) Standard Horizon VHF Radios |
• |
Hailer: (1) Raytheon 30 Watt Hailer |
• |
Fathometer: Furuno High Frequency Depth Sounder |
• |
Radar: (1) Furuno Radar |
• |
Standard Horizon GPS Plotter |
• |
Digital Compass |
• |
SIMRAD Robertson AP-11 Autopilot |
• |
High frequency private communications system |
|
|
| Equipment: |
• |
Lifting Straps |
• |
Cargo Nets |
• |
Electric Pumps |
• |
(3) Perko Searchlights |
• |
Underwater Epoxy |
• |
A compliment of salvage and dive equipment available upon request |
|
|
| Fuel Consumption: |
• |
Station Keeping - 10 GPH |
• |
Cruise (14 Knots) - 20 GPH |
• |
At Anchor - 4 GPH |
| |
|
| Range: |
• |
400 Miles @ Cruise Speed |
|
)
)
)
)
)
